shotmaster

When size matters, the capacity to produce 4 espressos at the same time on 28 cms of space.

Key Features shotmaster

  • 28 cms of space.
  • 350 Espressos per hour.
  • 4 Espressos simultaneously.

350 espressos / hour

at 23 s extraction time or

120 hot water units / hour /

200 ml (6.8 oz US)

4 espressos at the same time.

Standard technical data

Power requirement

Single-phase 1 x 230 V, 1L-N-PE, 25 A, 50/60 Hz, 5.8 kW
Two-phase 1 x 208 V, 2L-PE, 30 A, 50/60 Hz, 4.9 kW
Three-phase 3 x 230 V, 3L-N-PE, 16 A, 50/60 Hz, 5.8 kW

Water

Stainless steel braided hose length = 2 m with screw G3/8", 0–4 bar

Drain

hose Ø = 16 / 22 mm, length = 2 m

Water quality

Total hardness 5 – 8 °dGH (89 – 142ppm)

Carbonate hardness: max. 6 °dKH (107 ppm)

pH value: optimal 7.0 –7.2

Interfaces

USB, SD-Card, Ethernet, Serial RS-232, CCI (24 VDC, 15 W)

Standby mode

Less than 2 Watts electrical consumption

Front lighting

Full colour LED, all colours and colour gradient adjustable

Specifications

Dimensions

280 x 600 x 713 (W x D x H)

11 x 23.6 x 27.9 (W x D XH)

Weight

60 kg (132 lb)

Brew chamber

2 x up to 24 g

Grinding

2 x drive ceramic grinder disk

User interface

2 x 8" colour touch screen

Bean hoppers

2 x 1.5 kg (3.3 lb)

Coffee spout height

70 mm to 165 mm (2.75 to 6.49 inch)

Coffee boiler size

2 x 1.6 Liter (0.85 gal US)

Power consumption

up to 9.0 kW

Options for shotmaster

Decaffeinated Powder chute

This option enables the user to produce decaffeinated products without mobilising a dedicated bean hopper.

Bean hopper lock

This option protects the integrity/quality of the beans, prevents shrinkage.

Under counter ground coffee disposal

In high volume sites, this option promotes continuous operation, without having to empty out the coffee grounds drawer.

CCI / CSI connectivity for credit systems

This interface capacity enables Eversys equipment to be linked to payment mechanisms.

LAN and Ethernet

LAN, a more stable option than WIFI, enables the machine to be connected/accessed via the internet.
